2DMP

EXPANDABLE UP TO 4 DOORS

TWO DOOR CONTROLLER
SDOC-5016

INCLUDES POWER FOR PANEL AND READERS WITH BATTERY BACK UP
Neptune is a comprehensive embedded OS and browser-managed access control system.
Proven with tens of thousands of installations, Neptune systems are fast and easy to set-up, provide enhanced features and are scalability.

Features

  • Each module functions as a Server, Expansion panel or Elevator
  • Out of the box ready browser managed
  • Embedded Linux operating system
  • 2 Doors – 4 Readers (In/Out)

Lock Power

  • 2 Relays (Lock/Aux)
  • 3 Inputs (REX, DPS,Aux) Global
  • UL Listed – 294 Series 7
  • 5 year hardware warranty

Quantity
USER MANUAL
QUICKSTART GUIDE
IP FINDER
FLYER
HIGH RES PIC
WIRE DIAGRAM
APPLICATION NOTE
NETWORK CONFIG GUIDE
Smart and Powerful features

Compact, but Impact.

TECHNICAL SPECIFICATIONS

Model2DMP
Operating SystemEmbedded Linux
Transactions> 60 per second
System Power Requirements115VAC - 35 Watt
Operating Temperature50°F to 95°F (10°C to 35°C)
Enclosure Size (W x H x D)14.25 x 14.25 x 3.75in (362 x 362 x 95mm)
Internal Power SupplyController & Readers Only
List Lock out put powerNA
Battery Backup Controllers, Readers, & Door Lock
Recommended Battery Type (battery is not included)12V, 7AH, Sealed Lead Acid with 0.187 inch terminals
Standby Power Requirements450mA @ 12V
Readers (Wiegand)4 Total, One In & One Out Reader for Each Door
Reader Power300mA @ 12V Max per Reader 1000mA @ 12V Max per System
Reader Power Request to Exit (REX) Input2 Total, One for Each Door
Door Position (status) Input2 Total, One for Each Door
Auxiliary Input2 Total, General Purpose
Tamper Digital InputYes
Power Fault Digital InputYes
Door Lock Output1 Form C Relay, 24V @ 2.0A
Auxiliary Output 11 Form C Relay, 24V @ 2.0A
